Meadows Crossing is student housing and retail complex located just steps away from Grand Valley State University Campus in Allendale, MI. The retail portion of Meadows Crossing includes Mully’s Bar & Grill, HIP Party Store, Gentleman’s Quarters Barber Salon, Cottage Inn Pizza, and Insomnia Cookies.

Student housing in Allendale is an extremely competitive market. The window of opportunity to attract a student and get them to commit to a housing situation is very slim. Also, the retail segment can be challenging for tenants located near a college campus. Outlets often need to make a years-worth of revenue in an 8 or 9-month span due to the school calendar. For that reason, maximizing exposure to potential customers is extremely important.

Originally, Meadows Crossing had an outdated static monument sign on a long, large brick base (see below). The original sign didn’t seem to match the brick base, and also offered limited signage for each tenant. The sign didn’t feature any changeable messaging options.

_{Old Signage at Meadows Crossing}

Benefits of New LED Sign

The goal of the project was to upgrade the signage for Meadows Crossing that would outshine every other sign nearby, bringing maximum exposure for student housing and their retail outlets. Meadows Crossing enrolled the help of Universal Sign Systems to come up with the perfect solution. To bring maximum exposure and create that WOW factor Universal decided to install the first ever 6mm LED display in all of west Michigan. Universal supplemented the LED sign with new tenant signage in a sleek black cabinet that tied the entire sign together.

Because of the high pixel density of the LED sign, Meadows Crossing was able to show any image, graphic, or video with breathtaking picture clarity while complying with the size limitations of the local jurisdiction. All of the other signs in Allendale were mostly 16mm displays which were only good for simple text. Because of the 6mm pixel spacing Meadows Crossing could now show high-def images of their townhomes, delicious cookies from Insomnia cookies, delicious pizza from Cottage Inn, and more. The new sign brought immediate buzz to the area, resulting in more renters and higher sales revenue for their tenants.

"When Glenn came to me with a request for a replacement multi-tenant sign that would be a cut above the rest, I knew the recently released 6mm Electro-Matic display was the perfect fit. The quality of the display and tight pixel pitch allowed for detailed advertisements in the limited space that we were allowed. Thanks to Alan and the Electro-Matic team for knocking it out of the park!"

— Nate Zevenbergen, Universal Sign, Inc.

"We have thoroughly enjoyed having the new 6mm, high-density, LED sign at Meadows Crossing. It helps us to market our brand to the college student community every day. It enables us to market our retail tenants and their businesses as well. Our student apartment community is the best off-campus housing option for GVSU students and this elegant sign beams our superb brand 24/7."

— Glenn Turek, President at Silveri Management

Fori Automation offers Global Design and Build of Automated Material Handling, Assembly, Testing and Welding Systems for the automotive & non-automotive industries. Their USA Global Headquarters are located in Sterling Heights, Michigan the company was looking to upgrade their lighting to LED’s.

Check out Electro-Matic’s process for upgrading Industrial Facilities and Warehouses to LED Lighting.

Technical Situation/Analysis
Fori Automation’s previous Halide lights were not energy efficient. They had a long list of halide lights including:

135 1000w Metal Halide
8 468w T5 8 Lamp Fluorescent
16 250w Metal Halide wall packs
2 250w Metal Halide canopy fixtures

Their current lighting solution generated 1,012,585 annual kWh, 153,787 watts.

Objective for Situation
1) To reduce the electrical usage while improving light levels and working conditions.
2) To use the Made in Michigan 15% utility rebate bonus to give Fori a larger rebate than other companies could provide.

Solution
A pre-site visit was performed to take existing light levels to verify what the client was looking for. A photometric analysis was performed on the space to ensure that the correct fixture was specified to provide the correct light levels. EM Visual found that 300w fixtures with a combination of T1S and L5W lenses fit the application and achieved high light levels on the ground and even light on the walls.

For this solution, EM Visual was able to include the same mounting and electrical plug that their existing fixtures used, to ensure easy installation. The installed sample fixture was chosen because it delivered the best spread of light with the least amount of glare. The transparency with the customer on cost, performance, and potential rebates set Electro-Matic above the competition.

Benefits
Electro-Matic Visual was able to stage the installation so that Fori’s daily operations were not affected. After installing 141 LED High Bay fixtures, Fori Automation’s energy consumption was reduced by 72%.

Final Rebate: $76,971.80
Return on Investment: 0.9 years

Products and Services Used on this Project

4-Bar AR Series (120w)
• 150w Housing
• 3’ Pendant Rod
• HBL4770C (15A 277 Vac) Plug

10-Bar AR Series (300w)
• 300w Housing
• 3’ Pendant Rod
• HBL4770C (15A 277 Vac) Plug

Electro-Matic's LED Lighting Turnkey Process

The Cardington-Lincoln Local Schools located in Cardington, Ohio are committed to leading all students to college, career, and civic readiness. To give the students the best chance of success with their athletics, Cardington was preparing to install a new gym floor. They were disappointed in their current lighting situation and wanted to make drastic improvements. Cardington High School felt that their gym lighting was not adequate.

To achieve a lighting level that met NCAA requirements, EM utilized photometrics to evaluate the lighting needs of the gym and make the recommendation that met Cardington High School's objective.The new floor and lighting created a whole different atmosphere in the gym. Cardington now showcases one of the most attractive gyms in the conference!

List products and services EM used:
Skylark High Bay

The Village of Hazel Crest is a diverse, 3.4 square mile community of 14,075 people located just 25 miles from Chicago that were building a new municipal center. Knowing they had very little visual communication with their residents, they thought the new municipal center would be a great opportunity to add some LED displays to act as entrance signs into the town. The customer was originally looking at a 16mm sign but after the demo/investigation process, they immediately said they need the 11mm LED display and added two locations to the job.

The city of Hazel Crest also wanted to use the displays to post emergency alerts, news, and events going on in the town. With our Fusion product and Lifetime Cellular contracts we were able to provide the city with three 11mm signs. With the Electro-Matic LED display they are now able to provide current and updated village announcements across all three different locations all from one place.

“We chose to go with Elector-Matic Displays based on their ability to act fast with replacement parts, and their industry leading 5 year Labor Warranty.” - Brian Mazurek, President/CEO,

List products and services Electro-Matic used:
Fusion 11mm 108x216
